TECHNICAL SPECIFICATION :
Poire 3m3.
Technical Specification:
Vat Size : 1,800MM dia X 1,450MM Length
Rate Volume : 3m3
Motor Rating : 90/1440HP/rpm
Rotor Speed : 300rpm
Operating Consistency : 3.0-4.0%
Impeller dia : 1,500mm
Screen Plate Perforation : 6- 8mm ( As per requirement )
Drive: V Belt
Material of Construction and Scope of supply:
- ▪ Body Fabricated out of SS-304, 8mm plate with stock inlet Nozzle for connection to Pulper reject line, Reject Discharge Nozzle, Air Vent connection and Inspection window with cover.
- ▪ SS-304 fabricated Extraction Chamber with Outlet connection.
- ▪ Supporting structure and base frame of MS.
- ▪ EN-8 Shaft with SS -304 Sleeve.
▪Stuffing Box with gland packing, Labyrinth ring. - ▪ Cast SS-304 Impellor.
- ▪ CI Bearings housing.
- ▪ FAG antifriction bearings.
- ▪ CI Drive & Driven Pulley. ▪Foundation Bolts & Belts.
- ▪ Motor & Motor Base Frame. ▪ Motor 90 HP , 1440 RPM
