SM2472 - EXCLUSIVE AGENCY

🖥 - VOITH ATMOS Tissue Machine, 5.4m trim, 240 tpd

Delivered new, but never installed - a unique opportunity!

Specification:

  • 5.4 meter width
  • Wire width: 5,410 mm (213”)
  • Design speed 2,000 m/min
  • Headbox speed 2,150 m/min
  • Principal grammage range ATMOS 16-25BD g/m2
  • Yankee dryer (16.8) 1,900 m/min 240 ADMTPD

The Voith rational behind the Atmos is to make high quality tissue enclosing as much air, with as little fiber as possible. Bulk and caliper are funda­mental quality features. They result in absorbency for towel or structural and surface softness for toilet paper – the main tissue products in terms of worldwide consumption.

The ATMOS machine was designed to operate in ATMOS mode to produce premium tissue with the ability to switch to conventional dry crepe machine for standard tissue production. ATMOS has proved to be opera­tionally simple and robust. It allows a high level of flexibility with regard to grade changes across the complete range, from structured premium to standard tissue, while operating efficiently on virgin fiber, as well as 100% recycled fiber.

Energy

One of the tissue producers’ major concerns is the energy cost increase in recent years, which has resulted in higher production costs and, thus, lower profit. Realizing the significant impact that energy has on overall production costs, Voith developed the ATMOS technology. This technology allows production from standard to premium tissue with the lowest energy consumption per ton and finished product when compared to other technolo­gies available in the market - up to 60%.

Fiber savings

It is a well known fact that fiber is the single most costly con­tributor to a tissue mill’s production expense. Combined with the special focus on saving natural resources, Voith developed the ATMOS technology to produce standard and premium tis­sue. ATMOS requires up to 30% less fiber when compared to other technologies available in the market, and at the same time, enables the production of premium tissue using either 100% recycled or virgin fibers.


FOR CONFIDENTIAL DETAILS OF THIS VERY UNIQUE OFFERING

PLEASE DOWNLOAD THE CONFIDENTIALITY AGREEMENT (LINK),

THEN COMPLETE, SIGN, AND RETURN A SCANNED COPY

TO SAXON MACHINERY, THE EXCLUSIVE SALES AGENT:

 mark@saxonmachinery.com
