SM0856 “NEW" C FORMER HEAD-BOX 2,810mm slice, (x 2 available)
MANUFACTURER COMER
CONDITION NEVER INSTALLED - STILL IN MANUFACTURERS PACKING
PRODUCT TISSUE
GRAMMAGE RANGE 15 - 33 gsm
CONSISTENCY 0,2 - 0.4 %
FURNISH VIRGIN PULP
OPERATING SPEED 1,500 m/mm
MAX DESIGN SPEED 1,700 m/min
MAX. FLOW 5,8000 Lit/mm
M/N. FLOW 54,000 Lit/min
DESIGN FLOW 44,000 Lit/min
POND WIDTH 2,810 mm
BY PASS DIMENSIONING 5 %
TOP LIP VERTICAL ADJUSTMENT MAX 15 WORK
TOP LIP CLEANING POSITION 80 mm (CLEANING)
