COMPRESSOR

Manufacture:                     INGERSOLL RAND

Model:                                C950-C155MX3

Serial no                             V8007.

Capacity                             154m3/min.

Intake Pressure                   97kpa.

Discharge Pressure             850kpa.

Intake Temperature             35 degrees.

Relative Humidity                80.

Cooling Water                     32 degrees.

Cooling water flow              922 l/min.

Rated Speed                       2975.

Motor Rating                      1,000kw.

Weight                                14,110kg.

Dimension                           5.1 x 2.1 x 2.
